Round conical poles

Street and park lighting play an important role in ensuring the safety and comfort of people in the urban environment. Correct lighting not only helps to navigate in the dark, but also creates a pleasant atmosphere and increases the aesthetic appeal of the area. That is why the choice of lighting poles is an important element in the planning of any urban space.

Metal poles for street and park lighting are designed for reliable placement of lamps at the optimal height. Poles are installed wherever it is necessary to improve visibility and safety (along roads, sidewalks, in parks, on squares). The height of the poles varies according to the purpose: for street lighting, poles with a height of 7 to 12 meters are used, for parks and squares — from 3 to 8 meters.

Round metal poles are one of the optimal solutions for street and park lighting. Such metal poles are made of rolled steel with a thickness of 3-4 mm. When choosing, it is important to take into account their technical characteristics, operating conditions and project requirements.

Round poles have a conical or cylindrical (tubular) shape of the trunk with a cross section in the shape of a circle. Conical poles have the form of a truncated cone, which allows to distribute the load evenly due to the gradual increase in diameter from the top to the bottom. This form of construction allows to reduce the weight of the pole and the cost of materials, while maintaining strength and aesthetic appearance.



According to the method of installation, lighting poles can be divided into:

• Flanged poles involve a flanged connection of the pole to the foundation block (an anchor unit that is concreted into the ground). A special flange is welded to the lower part of the pole, which is connected to the anchor unit using nuts. This design makes it possible to easily replace a damaged pole (for example, in the event of a car accident) without the need to dismantle its foundation part.

• Upright poles (with ground installation) are installed by deepening the pole directly into the ground. At the same time, it is important to consider the pole’s height, because part of the pole will be placed underground, which will lower the lighting point.



The installation of metal poles involves only underground feeding of the power cable. This contributes to additional protection of cable lines and gives poles a more aesthetic appearance. For the convenience of maintenance, a special inspection hatch is placed in the pole.



The following advantagesof the metal round conical poles should be highlighted:

• LONG SERVICE LIFE:
  Metal poles made of high-quality rolled steel are resistant to mechanical damage, vibrations and other dynamic loads typical of operation in street conditions.

• CONVENIENCE IN INSTALLATION AND MAINTENANCE:
  Metal poles are easier and more convenient to install compared to reinforced concrete ones, as they have less weight, which simplifies transportation and installation. Their design also allows for faster assembly and disassembly without the need for heavy equipment. In addition, quite often, the process of installing metal poles does not require long preparation, and they can be installed without significant foundation work.

• MODERNITY AND AESTHETIC APPEARANCE:
  The elegant design of round poles adds a modern look to the urban space.

• HIGH ANTI-CORROSION RESISTANCE OF THE COATING:
  Our products are protected against corrosion by hot-dip galvanization. Thanks to the protective layer of zinc with a thickness of 80 to 120 microns, the poles are able to withstand even the most aggressive environmental conditions. Such processing significantly extends their service life — up to 70 years.

• THE POSSIBILITY OF PAINTING IN ANY COLOR ACCORDING TO THE RAL TABLE:
  The poles can be additionally painted with powder paint in any color. This allows to choose a color that will correspond to the corporate style or will allow to harmoniously fit into the aesthetics of the location (for example, in parks, black poles are often placed).



Round metal lighting poles are a reliable solution that allows to combine functionality and attractive design of outdoor space. Due to their high technical characteristics and durability, they are able to meet the needs of both modern urban environments and those with historical value. The choice in favor of such poles becomes an investment in safety and comfort that will serve for many years.
